Rated Input: 85 - 264VAC 1Φ
Rated Output Wattage: 20W
Rated Output Voltage: 5V, 12V, 15V, 24V
• Small size
• 1"×1.5" (TEPS10F/20F) ,1"×2.3" (TEPS45F/65F)
• Harmonic attenuator (Complies with IEC61000-3-2)
• All in one type
• ClassII: No FG connection is necessary
Free warranty period 5-year (Refer to Instruction Manuals)
One of the world’s smallest standard power supplies.
Compatible with a wide range of applications, from industrial equipment to building systems and consumer devices.
By achieving high efficiency and low power consumption, it contributes to green energy initiatives.
| Type | Model number | Description | DXF |
|---|
| CAD data | DXF |
Standard model
N: with Cover |
|---|---|---|
| 3D CAD data | STEP |
Standard model
N: with Cover |
| IGES |
Standard model
N: with Cover |
Single phase 250VAC 3A
Compact size
Low leakage current type
1-stage filter
TEP(1) S(2) 20(3) F(4) □□(5) - □(6)
(1) Series name
(2) Single output
(3) Output wattage
(4) Universal input
(5) Output voltage
(6) Optional
* For further information and how to use, please see in Cosel product catalog.
